Dune HD Remote

Logo

Control Dune HD media players via IP network from ioBroker.

Dune HD produces high-quality network media players supporting 4K HDR playback, Blu-ray, and a wide range of media formats. All Linux-based Dune HD players support IP control via HTTP API, which this adapter uses to provide full remote control from ioBroker.

Features

Full playback control (play, pause, stop, seek, prev/next, fast-forward/rewind)
Navigation (D-pad, enter, return, menus)
Volume and mute control
Status polling (player state, position, duration, volume, bitrate, audio language, video resolution)
Built-in PWA web remote — use your phone as a remote control
Smart offline polling — reduces poll frequency when player is unreachable
PWA text input — send text directly to the player's on-screen keyboard
PWA Play URL — start media playback from any URL directly from the remote

Supported Models

All Dune HD media players with IP control support (Linux-based firmware).
Tested on: Dune HD Pro 4K (firmware with XML response format).

Model type	Default port
Linux-based (Pro 4K, Solo 4K, etc.)	80
Android/ATV-based	11080

Configuration

Player

Field	Description
Player Name	Display name (for reference only)
Player IP Address	IP address of the Dune HD player
Player Port	HTTP port (default: 80)
Connection Timeout	Request timeout in ms (default: 5000)

Status Polling

Field	Description
Enable Status Polling	Enable periodic status updates
Polling Interval	Interval in seconds when player is online (default: 5)
Offline Polling Interval	Interval in seconds when player is unreachable (default: 30)

PWA Remote Control

Enable the built-in web remote to control the player from any browser or mobile device.

Field	Description
Enable PWA Remote Control	Start the built-in web server
Bind IP Address	Network interface to bind to (0.0.0.0 = all interfaces)
PWA Server Port	Port for the web remote (default: 8765)

After enabling, open http://<iobroker-host>:8765/ in your browser.
The URL is also stored in the info.pwaUrl state.

PWA features:

Main tab: D-pad, playback controls, volume, seek
Main tab: text input field — sends text to the active player keyboard (set_text API)
Main tab: Play URL field — starts media playback from any URL (launch_media_url API)
Digits tab: number keys, color buttons (A/B/C/D), subtitle, zoom, eject, REC
Settings tab: dark/light theme, connection settings
Works as installable PWA on iOS and Android (Add to Home Screen)

Dune Notify Plugin

Show notifications from ioBroker on top of the video during playback.
Requires the dune-notify PHP plugin installed on the player (see dune-notify/ folder).

Field	Description
Enable Notifications	Enable the dune-notify integration
Notify Request Timeout	HTTP request timeout in ms (default: 3000)

States

State	Type	Description
`info.connection`	boolean	Player reachable
`info.pwaUrl`	string	PWA remote URL
`info.playerModel`	string	Player model name
`info.firmwareVersion`	string	Firmware version
`status.playerStatus`	string	playing / stopped / paused
`status.position`	number	Playback position (seconds)
`status.duration`	number	Total duration (seconds)
`status.volume`	number	Volume level
`status.mute`	boolean	Mute state
`status.caption`	string	Current media title
`status.audioLang`	string	Audio language
`status.videoWidth/Height`	number	Video resolution
`status.bitrate`	number	Current bitrate (bit/s)
`control.play/pause/stop`	boolean	Trigger playback actions
`control.volume`	number	Set volume
`navigation.up/down/left/right/ok/back`	boolean	Navigation buttons
`media.playUrl`	string	Play media from URL
`media.seek`	number	Seek to position (seconds)
`notify.send`	string	Send notification (text or JSON)
`notify.hide`	boolean	Hide current notification
`notify.lastResult`	string	Result of last notification request

Changelog

1.2.5

Migrate i18n to short format ({lang}.json)
Update adapter-core range to ^3.4.3 in package.json

1.2.4

Update @iobroker/adapter-core to 3.4.3

1.2.3

Fix W0066: downgrade @types/node to >=22 <23
Add extends clause to tsconfig.json (@tsconfig/node22)
Add 1.2.2 changelog entry to README

1.2.2

Fix W5612: add missing i18n keys for notify section (all 11 languages)
Add prettier.config.mjs, tsconfig.json, @types/node, @tsconfig/node22
Update devDependencies (eslint-config 2.3.4, release-script 5.2.1)
Fix jsdoc types in lib files

1.2.1

Fix E8915: add dependabot cooldown (7 days) to reduce supply chain risk
Fix deploy step: use Node.js 24 for trusted publishing compatibility
Remove redundant eslint and prettier devDependencies (included via @iobroker/eslint-config)
Add manufacturer link and device description to README
Add CHANGELOG_OLD.md for older changelog entries

1.2.0

Add dune-notify plugin integration: show notifications on screen during playback
New states: notify.send, notify.hide, notify.lastResult
New config options: notifyEnabled, notifyTimeout

1.1.5

Fixed README: added missing changelog entry for 1.1.4

1.1.4

Fixed README changelog (E6006), added needs: check-and-lint to adapter-tests job (S3014)

1.1.3

Use standard workflow and testing scripts as provided by create-adapter
Added needs: check-and-lint to adapter-tests job
Restructured test directory to match ioBroker.example template

1.1.2

Use node: prefix for all built-in Node.js modules (fs, http, path, url)

1.1.1

Fixed prettier formatting errors in lib files
Added test:integration script for CI/CD compatibility

For older changelog entries see CHANGELOG_OLD.md.
