Omoda / Jaecoo | ioBroker

Monitor and control Omoda / Jaecoo (Chery) vehicles: status, location, battery/charging, lock and climate.

# ioBroker.omoda

omoda adapter for ioBroker

Brings your Omoda / Jaecoo car into ioBroker: vehicle status, GPS location, battery/charging, and remote lock and climate — using the same cloud backend as the official Omoda / Jaecoo app.

⚠️ Unofficial, reverse-engineered software. Not affiliated with, endorsed by, or connected to Omoda, Jaecoo or Chery. Provided "as is", use at your own risk and only on your own vehicle. Names and trademarks belong to their respective owners. See the LICENSE.

What it does

Status — doors, windows, sunroof, lock, engine, climate running, tyre pressures/temperatures.
Location — GPS latitude/longitude, speed, heading.
Battery & charging — state of charge, electric/total range, charge state, charging power, charge plug connected, remaining charge time.
Commands — lock/unlock, climate on/off with a settable target temperature, request GPS location, and "wake & refresh full status".

Additional functions from the vehicle app (individual seat heating/ventilation, defrosters, EV charge start/stop and scheduled charging, windows/sunroof/trunk control, theft alarm) are planned for a later version.

Requirements

An Omoda / Jaecoo account with the vehicle associated (owner or delegated access).
The account email and command PIN.
Region: defaults to Europe (also confirmed working in the UK). Other markets can be configured under Region & polling in the adapter settings.

Tip: consider using a delegated second account for the adapter. Logging in with the same account here and in the official app makes the two repeatedly log each other out.

Setup

Install the Omoda / Jaecoo adapter from the ioBroker admin Adapters tab and create an instance.
On the Account tab, enter your email and command PIN and save.
On the Login (OTP) tab, press Request OTP code — a one-time code is emailed to you.
Enter the code and press Confirm OTP. The adapter logs in and discovers your vehicle(s), creating a device per VIN under omoda.0.<VIN>.

A new OTP is only needed if the session later expires (typically because the official app was opened); otherwise the session is refreshed automatically.

Notes & safety

The command PIN is your account PIN. Entering a wrong PIN repeatedly can lock the account, so the adapter stops after a couple of failed attempts — re-check the PIN in the settings before retrying.
Many values read null while the car is in standby; battery, speed and mileage update while driving or charging, or after pressing Refresh full status (which briefly wakes the car).
Waking the car is rate-limited by the backend, so the adapter enforces a cooldown.
The MQTT telemetry connection uses mutual TLS. The client certificate/key material and the pinned CA ship with the adapter in data/certs-store.json (encrypted, as recovered by the upstream HA integration) so the adapter works offline without a provisioning round-trip. If Chery ever rotates the MQTT CA or client certs, that file has to be regenerated and a new adapter version released — telemetry will fail to connect until then.

Credits

This adapter is a port of the excellent reverse-engineering work in the Home Assistant integration omoda-jaecoo-ha by Caslinovich and JackRonan. The protocol constants, request-signing formulas, MQTT credential derivation, and endpoint recipes were recovered by them and are used here under the MIT License — this project would not exist without their effort. Please star and support the upstream project. All bugs in this ioBroker port are mine, not theirs.

Changelog

0.2.0 (2026-08-10)

(Alan Paris) BREAKING: commands.lock now follows the ioBroker switch.lock spec — true UNLOCKS the car, false locks it. Any script writing true to lock must be inverted. This is the polarity Alexa/Google (via ioBroker.iot), VIS lock widgets and type-detector already assume, so the old behaviour unlocked the car when the user asked to lock it
(Alan Paris) Fixed telemetry fields the car reports as null being stored as real values: doors.locked no longer reads "locked" when nothing was reported, and GPS no longer jumps to latitude/longitude 0
(Alan Paris) info.connection now returns to false when the session expires (e.g. the official app logs in on the same account) instead of staying true while every poll silently failed
(Alan Paris) Corrected the "Dept ID" help text in all 11 languages — the default is 44 (UK), not 39
(Alan Paris) The OTP code is now encrypted at rest, not only marked protected
(Alan Paris) location.heading uses a plain value role (value.direction is an up/down/opening enum, not a compass bearing)
(Alan Paris) Car MQTT reconnects back off from 10 s to 2 min and stop repeating the same warning, instead of retrying every 10 s forever when the broker keeps rejecting us
(Alan Paris) The captcha solver yields to the event loop, so it can no longer stall other adapters sharing a compact host process
(Alan Paris) Removed unused constants, token-store helpers and the placeholder test file
(Alan Paris) Default "Dept ID" is now 44 (UK) instead of 39 (IT) — existing instances keep the value they already have (upstream 37f8f2b)
(Alan Paris) Fixed a stale "charge remaining time": the field vanishes from the payload when charging ends, so the state now clears instead of showing the last value for hours (upstream a0f61ed)
(Alan Paris) Command confirmations no longer cry "check failed" when the car reports only the climate module — the backend includes it on nearly every successful OFF command (upstream 2cc7d56)
(Alan Paris) Backend rejections caused by vehicle permissions or a malformed request (A00374/A00554/A00567/A00604/A00643/A00757) no longer count towards the wrong-PIN anti-lockout (upstream 8aa4176)
(Alan Paris) Correct state roles for info.model and info.brand; account email marked as protected
(Alan Paris) The charging/driving fast-follow poll now self-schedules, so a slow probe can no longer overlap the next one

0.1.1 (2026-07-18)

(Alan Paris) Security: never log the VIN or MQTT user id in cleartext (masked to a short suffix)
(Alan Paris) Fixed a leak of the car MQTT client and polling timers when re-logging in after a session drop
(Alan Paris) Added credit to the upstream Home Assistant integration (JackRonan/omoda-jaecoo-ha) in the README and LICENSE
(Alan Paris) Added full admin UI translations for all 11 languages
(Alan Paris) Config: clearer "Dept ID" help — it must match your account country's dialing code (UK=44, IT=39, …)
(Alan Paris) Require Node.js >= 22 and admin >= 7.6.17; enabled automated npm publishing via trusted publishing (OIDC)
(Alan Paris) Marked the OTP code as protected; various adapter-checker compliance fixes

0.1.0 (2026-07-18)

(Alan Paris) initial release
