Discord

This ioBroker adapter integrates a Discord bot into ioBroker.

The adapter will create an object tree including objects and states for server and channel where the bot is on. Also an object tree with all users seen by the bot will be created.
Using this states, it's possible to receive and send messages and files on Discord.

Additionally, the adapter can register Discord slash commands to get and set ioBroker state values.

• Features
• Creating a Discord bot
• Adding the bot to a server
  • Remove the bot from a server
• States
  • discord.0.bot.*
  • discord.0.raw.*
• Authorization
• Messages
  • Receiving messages
    • Using text2command
  • Sending messages
    • Sending simple texts
    • Sending files
    • Sending reactions
    • Sending replies
    • Sending special custom messages
• Slash commands
  • Configure states for slash commands
  • Get states
  • Set states
  • Get an overview about states configured for slash commands
  • Custom slash commands
    • Structure of a custom slash command json state
• Blockly
  • Blockly example: Send a message to a user and edit it after three seconds
  • Blockly example: Send a composed message with an embed and two file attachments
  • Blockly example: Listen to custom slash command executes and send an image of the requested IP cam
• Usage in scripts
  • Send a message from a script
  • Edit a message from a script
  • Delete a message from a script
  • Add a reaction emoji to a message from a script
  • Await reactions to a message in a script
  • Reply to a custom slash command from a script
  • Get information about a server in a script
  • Get information about a server channel in a script
  • Get information about a user in a script
  • Get information about a server member in a script
  • Get information about a previous message in a script

Features

• ioBroker states for all servers of the bot to receive and send messages
• ioBroker states for all users seen by the bot to receive and send direct messages
• Simplified Discord server join and leave for the bot
• Set the bot status including actions
• Optional observe user presence status
• Optional observe server member voice status
• Server member voice actions (mute, deafen, disconnect)
• Handle all messages or only messages with bot mentions on server channels
• Handle direct messages
• Optional automatic react with a emoji on mentions
• .json states for channel, user and message data
• Send messages, files, reactions (emojis), reply messages, or custom json-formated message contents
• List server and channel members including member roles
• Support for Discord slash commands to get and set state values
• Support for user defined Discord slash commands to be handled by custom scripts
• Support for text2command (has to be enabled for each .message state where it should be used)
• Send, edit and delete messages, add and await message reactions using Scripts
• Optional raw states to allow more flexibility in custom scripts
• Support for Blockly with custom blocks to send and edit messages and to handle custom slash commands

What's not supported and not intended:

• Messages in threads
• Send and receive voice messages

Missing some feature? Feel free to submit a feature request on GitHub.

Creating a Discord bot

To use this adapter, you need to create a Discord bot application.

1. Got to the Discord Developer Portal and login with your Discord account if not already logged in.
2. In the Applications view, click the button New Application in the top right.

3. Choose a name for your application (this will be the name of your bot) and click Create.

4. (Optional) Upload an App Icon, edit the Name, edit the Description, add some Tags and Save Changes.

5. Navigate to Bot in the left menu and click the Add Bot button.

   In the following dialog click Yes, do it! to confirm the bot creation.
6. When the bot is created, you need to click the Reset Token button once to get you bot token.

   Since this will invalidate any former token, you need to confirm this by clicking the Yes, do it! button in the dialog popping up.
   After this, your token is displayed once and you should copy it to a secure place (e.g. the adapter instance configuration).
7. Scroll down a bit at the Bot page to the Privileged Gateway Intents and enable Presence Intent, Server Members Intent and Message Content Intent. Don't forget to click Save Changes.

   Note: Once your bot reaches 100 or more servers, the intents will require verification and approval.
8. Now you are ready to start the adapter instance and add the bot to a Discord server.

Adding the bot to a server

To add the bot to a server, you need to go to the adapter instance configuration to the tab Add bot to server. There you get a link which you can use to add the bot to a server, while setting the correct scopes and permissions.

The following bot permissions are required:

• Change Nickname
• Read Messages/View Channels
• Moderate Members
• Send Messages
• Embed Links
• Attach Files
• Read Message History
• Mention Everyone
• Add Reactions
• Mute Members
• Deafen Members
• Move Members

Also the following scopes are required:

• bot
• applications.commands

If some of the above permissions or scopes are missing, some features of the adapter might not work.

Remove the bot from a server

To remove the bot from a server, you may use the server select field on the same adapter instance configuration page. Just select the server and click the button to instruct the bot to leave the server.

States

Each server, channel and user is identified by its unique numeric ID.
Because names may change, the object tree created by the adapter uses these IDs to create a reliable structure.

The whole object tree is built from what bot can see. So it is possible, for example, that a server has more channels as displayed.

discord.0.bot.*

This is used to set the presence status and activity of the bot which should be displayed to users.

discord.0.servers.<server-id>.*

discord.0.servers.<server-id>.channels.<channel-id>.*

For all message* and send* states see Messages section below.

discord.0.servers.<server-id>.members.<user-id>.*

For the voice* states to be up to date, the option Observe user voice state in the instance configuration must be enabled.
To use the voiceDisconnect, voiceServerDeaf and voiceServerMute actions, the bot needs to have the related permissions on the server.

discord.0.users.<user-id>.*

For the status and activity* states to be up to date, the option Observe user presence in the instance configuration must be enabled.

For all message* and send* states see messages section below.

discord.0.slashCommands.<command-name>.*

If custom commands are enabled in the adapter instance configuration, the following states will be present.

All this states will be updated on each call of the custom command.

Note: It's recommended to use the json state in custom scripts to prevent overlaps. Example: A custom script reads the single option-* states while some user called the command again and the options from the first and the second command get mixed up.

discord.0.raw.*

If raw states are enabled in the adapter instance configuration, the following states will be present.

Note: These states contain raw data without any checks, filters or modifications by the adapter. A server will be named guild.

Authorization

By default, authorization is enabled and only authorized users are able to interact with the adapter.

The authorized users and server roles can be configured in the adapter instance configuration including some per user/role permissions.
For server roles, the permissions only apply to the specific server and not to other servers or direct messages.
If permissions are given per user and server role, they will be merged for the corresponding server.

The users and roles are identified by their internal ID, so changes of the user tag, user name or role name don't affect the authorized users/roles lists.

It's possible to disable the authorization, but this should be done only if any user on any server of the bot can be trusted!

Messages

The adapter is able to receive and send messages from/to discord text channels and users.

By default, in channels only messages with mentions of the bot are processed. To process messages without mentions too, the option Process all messages in server channels needs to be enabled in the instance configuration.

When a messages with a bot mention is received, the adapter will react to the message with an emoji. This can be customized in the adapter instance configuration.
If authorization is enabled, the bot will only react on mentions of authorized users.

Receiving messages

Received messages will be stored in the .message* states of the channel object for server channel messages or of the user object for direct messages.

If authorization is enabled, by default only messages from authorized users will be stored. This can be configured using the option Process messages from unauthorized users in the adapter instance configuration, so that all received messages, even from unauthorized users, will be stored.

The last received message per channel/user is always stored in the .message state. The timestamp, author and ID of the last received message is stored in the appropriate states.
Additionally all these information are stored in json format in the .messageJson state.

Using text2command

To use text2command, a text2command instance must be selected in the adapter instance configuration.

For each .message state the custom option Enable text2command for this state can be activated.
When activated, each received message will be send to the selected text2command instance.

The response from text2command is send as a reply, send as a normal message or not send, depending on the adapter instance configuration.

Sending messages

To send a message, you can write contents to the .send* states of a channel or a user.

Sending simple texts

To send a simple text, just write the text into the .send state of your target.
You may use Discord Markdown for text formatting like in your Discord client.

To mention a user, you can use the user ID in the form <@user-id>.
For group mentions use <@&group-id> and for channel mentions use <#channel-id>.

Examples: This is my message., This is _my_ **formatted** message., Hey <@490222742801481728>!

Sending files

To send a file as an attachment, you can write the file location into the .sendFile state of your target.

The file location may be a …

• Absolute or relative path to a local file.
  Relative paths are relative to the adapter directory of your ioBroker installation.
  The path may optionally be prepended by file://. Examples: /home/user/image.png, ../../iobroker-data/files/myfile.txt, file:///tmp/image.jpg

• URL to a remote file.
  Example: https://www.iobroker.dev/images/iobroker.png

• Base64 encoded file content.

Additionally, you may add a text message to the file. To do so, just write the file location, followed by a pipe character | and your message into the .sendFile state.
Examples: /tmp/image.png|This is my file, https://www.iobroker.dev/images/iobroker.png|The ioBroker logo

Sending reactions

Using the .sendReaction state you can react to a previous message with an emoji. To do so, just write the emoji into the state.

By default, the reaction will be send for the message which is currently in the corresponding .messageId state.

If you want to react to a specific message, you can write the message ID, followed by pipe character | and the emoji into the .sendReaction state.

Examples: 👍, 971032590515568660|👍

Sending replies

Using the .sendReply state you can send a reply to a previous message. To do so, just write the reply message into the state.

By default, the reply will be send for the message which is currently in the corresponding .messageId state.

If you want to reply to a specific message, you can write the message ID, followed by pipe character | and the reply message into the .sendReply state.

Examples: This is a reply., 971032590515568660|This is a reply.

Sending special custom messages

You can send special custom messages writing a stringified JSON message object into the .send or .sendReply states.

The JSON object must of type MessageOptions. For more information read the discord.js MessageOptions documentation.

Examples:

Send an image:

{
  "files": [
    {
      "attachment": "/tmp/image.jpg",
      "name": "image.jpg",
      "description": "My super image"
    }
  ]
}

Send embedded content:

{
  "content": "Use this:",
  "embeds": [
    {
      "title": "ioBorker.discord",
      "description": "Discord adapter for ioBroker",
      "color": "#5865f2",
      "url": "https://github.com/crycode-de/ioBroker.discord",
      "author": {
        "name": "Peter Müller",
        "url": "https://github.com/crycode-de"
      },
      "image": {
        "url": "https://github.com/crycode-de/ioBroker.discord/raw/main/admin/discord.png"
      },
      "footer": {
        "text": "❤👍"
      }
    }
  ]
}

Send embedded image from local source:

{
  "embeds": [
    {
      "title": "IP-Cam Alert",
      "description": "Look at this:",
      "color": "#ff0000",
      "image": {
        "url": "attachment://cam.jpg"
      }
    }
  ],
  "files": [
    {
      "attachment": "http://192.168.1.50:8080/ip-cam.jpg",
      "name": "cam.jpg"
    }
  ]
}

Slash commands

If enabled in the adapter instance configuration, the adapter is able to handle Discord slash commands. These commands can be used to get or set ioBroker states.

Note: You need to configure the states individually, which you want to be available for Discord slash commands. See below.

Discord slash commands can be registered as server commands (default) or as global commands by the adapter. This can be configured in the adapter instance configuration.
Using server commands has the benefit, that changes to the commands (e.g. added states) are applied instant without any delay. But server commands can't be used in direct messages between a user and the bot.
Global commands can be used in direct messages too, but any change to the commands may take up to one hour to apply. This is a limitation from Discord and not the adapter.

The default used slash commands are /iob-get and /iob-set. The command names and descriptions can be configured in the adapter configuration.

Configure states for slash commands

For each state which should be available for Discord slash commands, you need to enable this in the custom settings of the state. To do so, just click the Custom settings gear icon in the Objects view in admin, enable the settings for your adapter instance and activate Enable discord commands for this state.

You can define a Name and an Alias for each state to be used in Discord. The Name will be shown in autocomplete options for the commands and the Alias is used as an internal identifier. Both must not exceed 100 characters.

For each state you can define individually if it should be available for set and/or get commands.
Also you can enable to show an information on get commands if the state is not acknowledged and to set a state with ack flag.

For string type state objects you may choose to treat the value as a file (file location).
If this is enabled, the state value will be send like in the .sendFile states.
Using this you can request images via get commands, for example.

For number type state objects you can define the number of decimals to round a value to on get commands.

For boolean type state objects you can define custom values for true and false values to show on get commands.

Get states

To get a state just call /iob-get state-alias in your Discord client.
For the state-alias an autocomplete will be shown while entering the command.

Any value will be formated as configured in the state object and the custom state settings. Optionally an information about a missing ack flag can be added.

Set states

To set a state just call /iob-set state-alias new-value in your Discord client.
For the state-alias an autocomplete will be shown while entering the command.
The new-value will be parsed by the adapter, if the state type is boolean or number.

You may configure per state, if the value should be set with or without ack flag.

For boolean type states, the values true, on, yes, 1 and their corresponding translations of your language, as well as your per state configured True value will be treated as true. Any other value would be treated as false.

For number type states, the provided value will be parsed as float number.
If your ioBroker is configured to use a comma in float numbers, you may provide the number with a comma or dot as float separator. Otherwise only a dot is allowed.
If min and max values are defined in the state object, they are also checked.

Get an overview about states configured for slash commands

To get an overview about all states where slash commands are enabled, you can simply click the button Log state objects configured for commands in the adapter instance configuration and see the log output.

Custom slash commands

In the adapter instance configuration, custom slash commands can be enabled and configured. The configured custom commands will be registered on Discord together with the default get and set commands.

For each custom command some options may be added, which will be shown in the Discord client when calling the command.
If an option is not provided on command call, the option value will be null.
For options of type string you may dynamically set predefined choices in the corresponding option-*.choices state as JSON array.

When a custom command gets called, the data will be written into re corresponding states. See the description of the states in the States section above.

All information including the option values will be stored in the .json state of the command. This state should mainly be used to get the command data in scripts since all needed information are stored in a single place and can't get mixed up on multiple command calls within a short time. For options of type user, role, channel or mentionable additional properties of the option object will be filled.

Note: It's up to you to handle the command data and send a reply to the command, i.e. using a custom script. You have up to 15 minutes to send a reply using the .sendReply state or the corresponding sendTo(...) action. If you don't send a reply in time, the Discord client will show the error message The application did not respond.

Hint: You may send a reply to one command call multiple times. This will edit the reply and set it to the new content.

Structure of a custom slash command json state

{
  interactionId: string,
  commandName: string,
  user: {
    id: string,
    tag: string,
    name: string,
    displayName: string,
  },
  channelId: string,
  serverId: string | null,
  timestamp: number,
  options: {
    [string]: {
      value: string | number | boolean | null,
      type: 'String' | 'Number' | 'Boolean' | 'User' | 'Role' | 'Channel' | 'Mentionable' | null,
      user?: { // if type is USER or MENIONABLE
        id: string,
        tag: string,
        name: string,
        bot: boolean,
      },
      member?: { // if type is USER or MENIONABLE and command is called on a server
        id: string,
        tag: string,
        name: string,
        displayName: string,
        roles: { id: string, name: string }[],
      },
      role?: { // if type is ROLE or MENTIONABLE
        id: string,
        name: string,
      },
      channel?: { // if type is CHANNEL
        id: string,
        name: string,
        type: 'GuildCategory' | 'GuildNews' | 'GuildStageVoice' | 'GuildStore' | 'GuildText' | 'GuildVoice',
        lastMessageId: string | null,
      },
    },
    // ...
  }
}

Blockly

The adapter ships with it's own Blockly blocks for ...

• Sending messages to users or server channels
• Edit messages in direct messages or server channels
• Add a reaction emoji to messages
• Compose message contents with optional embeds, attachments and reply reference
• Compose message embeds
• Compose message attachments
• Listen to custom slash commands
• Reply to custom slash commands

Blockly example: Send a message to a user and edit it after three seconds

<xml xmlns="https://developers.google.com/blockly/xml">
  <variables>
    <variable id="KIILW$,(eB?pT`;GDuMF">messageId</variable>
  </variables>
  <block type="discord_send_message_user" id="?xkCV};-Lk_-|Q`]%(Gt" x="163" y="38">
    <field name="instance">.0</field>
    <field name="logResultOk">FALSE</field>
    <value name="user">
      <shadow type="text" id="jXN@CluUy_M/ig@4[(Uk">
        <field name="TEXT">crycode</field>
      </shadow>
    </value>
    <value name="content">
      <shadow type="text" id="uLWu1CJ$;k}|VTyw1-8}">
        <field name="TEXT">Hallo!</field>
      </shadow>
    </value>
    <value name="varMessageId">
      <shadow type="logic_null" id="bJ2lJW0qOa@Zjv%(]mFU"></shadow>
      <block type="variables_get" id="xkJ(vH/;@7%)cDo0HU/~">
        <field name="VAR" id="KIILW$,(eB?pT`;GDuMF">messageId</field>
      </block>
    </value>
    <value name="varError">
      <shadow type="logic_null" id="H:f+1-:p9-YkmpehJoco"></shadow>
    </value>
    <next>
      <block type="timeouts_wait" id="OM8gv}Pl#_mHQ|)([mUe">
        <field name="DELAY">3</field>
        <field name="UNIT">sec</field>
        <next>
          <block type="discord_edit_message_user" id="|L3A+9{s_H8j`AF@,*VF">
            <field name="instance">.0</field>
            <field name="logResultOk">FALSE</field>
            <value name="user">
              <shadow type="text" id="voJ:{uuYtbBZ!Xe,rtV|">
                <field name="TEXT">crycode</field>
              </shadow>
            </value>
            <value name="messageId">
              <shadow type="text" id="64L=tOKvKwoqGHadRgDm">
                <field name="TEXT"></field>
              </shadow>
              <block type="variables_get" id="(M^6xk74LUEsPdH=LagL">
                <field name="VAR" id="KIILW$,(eB?pT`;GDuMF">messageId</field>
              </block>
            </value>
            <value name="content">
              <shadow type="text" id="rvnV^RF,g$M/3+(npHNC">
                <field name="TEXT">Moin!</field>
              </shadow>
            </value>
            <value name="varError">
              <shadow type="logic_null" id="{H4Q^vl400kxRKrffDz)"></shadow>
            </value>
          </block>
        </next>
      </block>
    </next>
  </block>
</xml>

Blockly example: Send a composed message with an embed and two file attachments

<xml xmlns="https://developers.google.com/blockly/xml">
  <block type="discord_send_message_server_channel" id="Mnc=pB-8%Dr/nsen|SC`" x="63" y="38">
    <field name="instance">.0</field>
    <field name="logResultOk">FALSE</field>
    <value name="serverId">
      <shadow type="text" id="PA4]t;7CuDrKtwa|oB?L">
        <field name="TEXT">813364154118963251</field>
      </shadow>
    </value>
    <value name="channelId">
      <shadow type="text" id="x^vm,CRT`z2AhDT#ZcUC">
        <field name="TEXT">813364154559102998</field>
      </shadow>
    </value>
    <value name="content">
      <shadow type="text" id="ebdEp~G?:_gInjN47g@f">
        <field name="TEXT"></field>
      </shadow>
      <block type="discord_create_content" id="kY,/zwmwkjo:U;cT?eN*">
        <value name="content">
          <shadow type="text" id="D|y(g`oE@H#gu+deGbv2">
            <field name="TEXT"></field>
          </shadow>
        </value>
        <value name="embeds">
          <shadow type="logic_null" id="Qt[pG25wLoI8+3/jN66C"></shadow>
          <block type="discord_create_embed" id="cXAWtP-36uYlAxLhIBhN">
            <value name="description">
              <shadow type="text" id="^D%m:ic9]AcUUQP8~U#6">
                <field name="TEXT">Embedded attachment</field>
              </shadow>
            </value>
            <value name="title">
              <shadow type="logic_null" id="_Wm.(^Ff6^u%K+gVz$^Z"></shadow>
            </value>
            <value name="url">
              <shadow type="logic_null" id="0,08A!7[kJ-nJPnPH$L5"></shadow>
            </value>
            <value name="color">
              <shadow type="colour_picker" id="V0}MlQJvN._LHFhG2K%@">
                <field name="COLOUR">#5865f2</field>
              </shadow>
            </value>
            <value name="imageUrl">
              <shadow type="logic_null" id="xXr:E++u0;@2#e]r;_`]"></shadow>
              <block type="text" id="76;;p-5{pls%KmrI!ar{">
                <field name="TEXT">attachment://file1.jpg</field>
              </block>
            </value>
            <value name="footerText">
              <shadow type="logic_null" id="#BS`MgkNWbrQ@*m/kNdw"></shadow>
            </value>
          </block>
        </value>
        <value name="files">
          <shadow type="logic_null" id="4u@7^DXCI~J$r{Qx}1Ql"></shadow>
          <block type="lists_create_with" id="42g8r-+[xWw`|^.qOF!*">
            <mutation items="2"></mutation>
            <value name="ADD0">
              <block type="discord_create_file" id="EzK4NA^+bu4vChH/vj-b">
                <value name="attachment">
                  <shadow type="text" id="=OEkBZ:LFXvT2$S++21(">
                    <field name="TEXT">/tmp/file1.jpg</field>
                  </shadow>
                </value>
                <value name="name">
                  <shadow type="text" id="zum#q*|`aD%A2s/N@/Ow">
                    <field name="TEXT">file1.jpg</field>
                  </shadow>
                </value>
                <value name="description">
                  <shadow type="text" id="#ZZOq%3EHO/_GC+w.,-^">
                    <field name="TEXT"></field>
                  </shadow>
                </value>
              </block>
            </value>
            <value name="ADD1">
              <block type="discord_create_file" id="wIKo-2??SX@WcYc7e/5s">
                <value name="attachment">
                  <shadow type="text" id=")4lvYv.)IhU/p+~KUDym">
                    <field name="TEXT">/tmp/logfile.txt</field>
                  </shadow>
                </value>
                <value name="name">
                  <shadow type="text" id="#)t#lK6{$RuZt34O;@Ag">
                    <field name="TEXT">log.txt</field>
                  </shadow>
                </value>
                <value name="description">
                  <shadow type="text" id="^UKzs+$TQ!tiE:`(=%}}">
                    <field name="TEXT"></field>
                  </shadow>
                </value>
              </block>
            </value>
          </block>
        </value>
        <value name="replyToId">
          <shadow type="logic_null" id="#1:[?d^x=)ZH.!uyxRI:"></shadow>
        </value>
      </block>
    </value>
    <value name="varMessageId">
      <shadow type="logic_null" id="@D^#9^84UknOfV|c$NK~"></shadow>
    </value>
    <value name="varError">
      <shadow type="logic_null" id="mJu{Fa9+]+Ml,{_OqIOh"></shadow>
    </value>
  </block>
</xml>

Blockly example: Listen to custom slash command executes and send an image of the requested IP cam

<xml xmlns="https://developers.google.com/blockly/xml">
  <variables>
    <variable id="Wcj[Gmy,vX]b,)s,O)`U">interactionId</variable>
    <variable id="{sXn[Mn@ZN#fWtTV6O^;">userName</variable>
    <variable id="ULmVI=-QcXLnD!e60KTV">camID</variable>
  </variables>
  <block type="discord_on_custom_cmd" id="GE,i32wKhz%KGlBhV$j=" x="63" y="13">
    <mutation xmlns="http://www.w3.org/1999/xhtml" options="cam"></mutation>
    <field name="instance">.0</field>
    <field name="varInteractionId" id="Wcj[Gmy,vX]b,)s,O)`U">interactionId</field>
    <field name="log">FALSE</field>
    <field name="commandName">super-command</field>
    <value name="varUserId">
      <shadow type="logic_null" id="/}0,E!Gq=C2U]C^.8m1@"></shadow>
    </value>
    <value name="varUserName">
      <block type="variables_get" id="Q=v?u?yU}Tw*@FH*|x7.">
        <field name="VAR" id="{sXn[Mn@ZN#fWtTV6O^;">userName</field>
      </block>
    </value>
    <value name="varUserTag">
      <shadow type="logic_null" id="+r2I4SpfhuW%9DE21,[c"></shadow>
    </value>
    <value name="option0">
      <shadow type="logic_null" id="hL^g}gJg-b.+SOH0s9m1"></shadow>
      <block type="variables_get" id="z/Lf|chD)~Ge0N~@EWG%">
        <field name="VAR" id="ULmVI=-QcXLnD!e60KTV">camID</field>
      </block>
    </value>
    <statement name="STATEMENT">
      <block type="discord_send_custom_command_reply" id="zJXF!F=|Xt4.kG/6ctl(">
        <field name="instance">.0</field>
        <field name="interactionId" id="Wcj[Gmy,vX]b,)s,O)`U">interactionId</field>
        <field name="logResultOk">FALSE</field>
        <value name="content">
          <shadow type="text" id="bdVm59S9_U*GFB(IBO6x">
            <field name="TEXT"></field>
          </shadow>
          <block type="discord_create_content" id="6m8gBtp;K@t8}{`9gPd1">
            <value name="content">
              <shadow type="text" id=".c}Z71nQ8LlQ@h}_Z?qR">
                <field name="TEXT"></field>
              </shadow>
              <block type="text_join" id="Z{wQ$[1g7z?KPMSHB],Y">
                <mutation items="3"></mutation>
                <value name="ADD0">
                  <block type="text" id="cuzUE7GB$#gC*;nOQ|Ke">
                    <field name="TEXT">Hi </field>
                  </block>
                </value>
                <value name="ADD1">
                  <block type="variables_get" id="|[[T@|n1Ro{EU56/jJ@P">
                    <field name="VAR" id="{sXn[Mn@ZN#fWtTV6O^;">userName</field>
                  </block>
                </value>
                <value name="ADD2">
                  <block type="text" id="LV$kS:Gzv#cJ#gXe/{4a">
                    <field name="TEXT">!</field>
                  </block>
                </value>
              </block>
            </value>
            <value name="embeds">
              <shadow type="logic_null" id="p8S?*FLv4a6aIJogCKU;"></shadow>
            </value>
            <value name="files">
              <shadow type="logic_null" id="y#a8q/mr^)Ymt*j)S:H/"></shadow>
              <block type="discord_create_file" id="vN%eoP74=*)f63CQiJ__">
                <value name="attachment">
                  <shadow type="text" id="2$9y5yj3.GHx.ms*:Ce2">
                    <field name="TEXT"></field>
                  </shadow>
                  <block type="text_join" id="K9zuKTz?-b8VT$8XUVQ8">
                    <mutation items="3"></mutation>
                    <value name="ADD0">
                      <block type="text" id="p3f^[{6t+UuDJN=49+#Z">
                        <field name="TEXT">/tmp/cam</field>
                      </block>
                    </value>
                    <value name="ADD1">
                      <block type="variables_get" id="oVmVHEX[iT(-X#]m=[U@">
                        <field name="VAR" id="ULmVI=-QcXLnD!e60KTV">camID</field>
                      </block>
                    </value>
                    <value name="ADD2">
                      <block type="text" id="wUXx)@u6*2,+9!q{W`n`">
                        <field name="TEXT">.jpg</field>
                      </block>
                    </value>
                  </block>
                </value>
                <value name="name">
                  <shadow type="text" id="L5fO_+by.^Z:se~6|xCj">
                    <field name="TEXT">cam.jpg</field>
                  </shadow>
                </value>
                <value name="description">
                  <shadow type="text" id="ku}h+v)9oY;1`[9Rr)w%">
                    <field name="TEXT"></field>
                  </shadow>
                </value>
              </block>
            </value>
            <value name="replyToId">
              <shadow type="logic_null" id="Ou%Gd6C*+2OaIPUxPp}t"></shadow>
            </value>
          </block>
        </value>
        <value name="varMessageId">
          <shadow type="logic_null" id="RUb!i][5`[t0*mzLwBvN"></shadow>
        </value>
        <value name="varError">
          <shadow type="logic_null" id="SLsj^+8=[Bp%/X8n]$?Z"></shadow>
        </value>
      </block>
    </statement>
  </block>
</xml>

Usage in scripts

You may use the sendTo(...) function in scripts to interact with the adapter instance.

Note: All used IDs are strings.

Send a message from a script

To send a message you can use the send or sendMessage command. They are the same.

The message part of sendTo(...) needs to be an object with the content to send and one of the following parameters to identify the target:

• userId
• userTag
• userName
• serverId and channelId

The content may be a simple string, or a MessageOptions object.

The return value in the sendTo(...) callback is an object containing your message parameters and a result string and the messageId of the sent discord message on success or an error message if there was an error.

Examples:

// send to user using the unique user name
sendTo('discord.0', 'sendMessage', {
  userName: 'crycode',
  content: 'Hi!',
}, (ret) => {
  log(ret);
  // {'result':'Message sent to user crycode','userName':'crycode','content':'Hi!','messageId':'971779972052155891'}

  if (ret.error) {
    log(ret.error, 'error');
    return;
  }
  log(`Message sent with ID ${ret.messageId}`);
});

// send to user using the user tag (for bots or users not migrated to unique user name)
sendTo('discord.0', 'sendMessage', {
  userTag: 'cryCode#9911',
  content: 'Hi!',
}, (ret) => {
  log(ret);
  // {'result':'Message sent to user cryCode#9911','userTag':'cryCode#9911','content':'Hi!','messageId':'971779972052160552'}

  if (ret.error) {
    log(ret.error, 'error');
    return;
  }
  log(`Message sent with ID ${ret.messageId}`);
});

// send a reply message to a user
sendTo('discord.0', 'sendMessage', {
  userId: '490222742801481728',
  content: {
    content: 'Ok!',
    reply: {
      messageReference: '971779972052160552', // ID of the message you want to reply to
    },
  },
}, (ret) => {
  log(ret);
  // {'result':'Message sent to user crycode','userId':'490222742801481728','content':{'content':'Ok!','reply':{'messageReference':'971779972052160552'}},'messageId':'971786369401761832'}
});

// send a file to a server channel
sendTo('discord.0', 'sendMessage', {
  serverId: '813364154118963251',
  channelId: '813364154559102998',
  content: {
    content: 'Look at this:',
    files: [
      {
        attachment: "/tmp/image.jpg",
        name: "image.jpg",
        description: "My super image"
      },
    ],
  },
}, (ret) => {
  log(ret);
  // {'result':'Message sent to channel Allgemein','serverId':'813364154118963251','channelId':'813364154559102998','content':{'content':'Look at this:','files':[{'attachment':'/tmp/image.jpg','name':'image.jpg','description':'My super image'}]},'messageId':'971780152759558234'}
});

Edit a message from a script

Using the editMessage command, you are able to edit a previous message.
Of course, you can only edit messages send by the bot.

The message part of sendTo(...) is the same as for sendMessage (see above) with the messageId of the message you want to edit as additional parameter.

The return value is the same as for sendMessage.

Examples:

// edit a message
sendTo('discord.0', 'editMessage', {
  userName: 'crycode',
  content: 'Hello!',
  messageId: '971495175367049276',
}, (ret) => {
  log(ret);
  // {'result':'Message edited','userName':'crycode','content':'Hello!','messageId':'971495175367049276'}
});

// send a message and edit it after five seconds
sendTo('discord.0', 'sendMessage', {
    userName: 'crycode',
    content: 'Now: ' + new Date().toLocaleString(),
}, (ret) => {
  if (ret.error) {
    log(ret.error, 'error');
    return;
  }
  setTimeout(() => {
    sendTo('discord.0', 'editMessage', {
      userName: 'crycode',
      content:  'Now: ' + new Date().toLocaleString(),
      messageId: ret.messageId,
    }, (ret2) => {
      log(ret2);
      // {'result':'Message edited','userName':'crycode','content':'Now: 5.5.2022, 16:25:38','messageId':'971779692166266920'}
    });
  }, 5000);
});

Delete a message from a script

Using the delteMessage command, you are able to delete a previous message.
Of course, you can only delete messages send by the bot.

The message part of sendTo(...) is the same as for sendMessage (see above) without the content but with the messageId of the message you want to delete as additional parameter.

The return value is the same as for sendMessage.

Example:

// delete a message
sendTo('discord.0', 'deleteMessage', {
  userName: 'crycode',
  messageId: '971495175367049276',
}, (ret) => {
  log(ret);
  // {'result':'Message deleted','userName':'crycode','messageId':'971495175367049276'}
});

Add a reaction emoji to a message from a script

Using the addReaction command, you are able to add a reaction emoji to a previous message.

The message part of sendTo(...) is the same as for sendMessage (see above) without the content but with the messageId of the message you want react to and the emoji as additional parameters.

The return value is the same as for sendMessage.

Example:

// add a reaction to a message
sendTo('discord.0', 'addReaction', {
  userName: 'crycode',
  messageId: '971786369401761832',
  emoji: '😎',
}, (ret) => {
  log(ret);
  // {'result':'Reaction added to message','userName':'crycode','messageId':'971786369401761832','emoji':'😎'}
});

Await reactions to a message in a script

You are able to await reactions (emojis) to a previous message using the awaitMessageReaction command.

The message part of sendTo(...) is the same as for editMessage (see above) without the content parameter but with timeout and max number as additional parameters.

The timeout is the maximum wait time to collect the reactions in a range from 100 to 60000 ms.

The max parameter defines the maximum number of reactions to collect. Default is 1 if not provided.

The callback of sendTo(...) will be called if either the timeout is reached or the specified number of reactions is collected.
The return value is an object containing your message parameters and a reactions array. Each reaction is an object of emoji, emojiId and users, where users is an array of objects with id and tag.
If a reaction is simple emoji, the emojiId will be null. For custom emojis, emoji will be the emoji name and emojiId will be set.

sendTo('discord.0', 'awaitMessageReaction', {
  serverId: '813364154118963251',
  channelId: '813364154559102998',
  messageId: '970754574879162458',
  timeout: 10000,
  max: 3,
}, (ret) => {
  log(ret);
  // {'reactions':[{'emoji':'👍','emojiId':null,'users':[{'id':'490222742801481728', 'name': 'crycode','tag':'crycode#0'}]}],'serverId':'813364154118963251','channelId':'813364154559102998','messageId':'970754574879162458','timeout':10000,'max':3}
});

Reply to a custom slash command from a script

Using the sendCustomCommandReply command, you can send a reply to a custom slash command call.

The message part of sendTo(...) needs to be an object with the content to send and the interactionId of the command call:

The content may be a simple string, or a MessageOptions object (like in sendMessage).

on({ id: 'discord.0.slashCommands.iob-test.json', change: 'any', ack: true }, (obj) => {
  log(`Got custom slash command ${obj.state.val}`);
  // Got custom slash command {"interactionId":"977265764136517725","commandName":"iob-test","channelId":"813364154559102998","serverId":"813364154118963251","user":{"id":"490222742801481728","tag":"crycode#0", "name": "crycode","displayName":"Peter"},"timestamp":1653068714890,"options":{"myopt":{"value":"test","type":"String"}}}

  const data = JSON.parse(obj.state.val);

  let reply;
  if (data.options.myopt.value) {
    reply = {
      content: `You gave me "${data.options.myopt.value}".`,
      embeds: [
        {
          title: 'This is awesome!',
          color: '#00AA00',
        },
      ],
    };
  } else {
    reply = `You gave me nothing. 🤨`;
  }

  sendTo('discord.0', 'sendCustomCommandReply', {
    interactionId: data.interactionId,
    content: reply,
  }, (ret) => {
    log(ret);
    // {'result':'Reply sent','interactionId':'977265764136517725','content':{'content':'You gave me \'test\'.','embeds':[{'title':'This is awesome!','color':'#00AA00'}]},'messageId':'977265765122183248'}
  });
});

Get information about a server in a script

sendTo('discord.0', 'getServerInfo', {
  serverId: '813364154118963251',
}, (ret) => {
  log(ret);
});

Get information about a server channel in a script

sendTo('discord.0', 'getChannelInfo', {
  serverId: '813364154118963251',
  channelId: '813364154559102998',
}, (ret) => {
  log(ret);
});

Get information about a user in a script

sendTo('discord.0', 'getUserInfo', {
  userId: '490222742801481728',
}, (ret) => {
  log(ret);
});

sendTo('discord.0', 'getUserInfo', {
  userTag: 'cryCode#9911',
}, (ret) => {
  log(ret);
});

Get information about a server member in a script

sendTo('discord.0', 'getServerMemberInfo', {
  serverId: '813364154118963251',
  userId: '490222742801481728',
}, (ret) => {
  log(ret);
});

sendTo('discord.0', 'getServerMemberInfo', {
  serverId: '813364154118963251',
  userTag: 'cryCode#9911',
}, (ret) => {
  log(ret);
});

Get information about a previous message in a script

sendTo('discord.0', 'getMessageInfo', {
  serverId: '813364154118963251',
  channelId: '813364154559102998',
  messageId: '978252795763359794',
}, (ret) => {
  log(ret);
});

sendTo('discord.0', 'getMessageInfo', {
  userId: '490222742801481728',
  messageId: '976090572760694814',
}, (ret) => {
  log(ret);
});

sendTo('discord.0', 'getMessageInfo', {
  userTag: 'cryCode#9911',
  messageId: '976090572760694814',
}, (ret) => {
  log(ret);
});

Changelog

2.6.1 (2025-10-25)

• (crycode-de) Updated Sentry DSN
• (crycode-de) Updated dependencies

2.6.0 (2025-10-21)

• (crycode-de) Node.js >= 20, js-controller >= 6.0.11, Admin >= 7.6.17 required
• (crycode-de) Updated dependencies

2.5.2 (2024-11-16)

• (crycode-de) Added missing sizes to jsonConfig

2.5.1 (2024-10-23)

• (crycode-de) Small style fixes for jsonConfig
• (crycode-de) Optimized timeout behavior
• (crycode-de) Updated dependencies

2.5.0 (2024-09-23)

• (crycode-de) Node.js >= 18, Admin >= 6.17, js-contoller >= 5.0.19 are required
• (crycode-de) Updated dependencies

2.4.0 (2024-07-10)

• (crycode-de) Added basic support for interactions unknown to the adapter (custom scripts required for handling)
• (crycode-de) Raw interaction JSON is now written to the state after the interaction is initially handled to prevent some race conditions
• (crycode-de) Updated dependencies

2.3.1 (2024-06-29)

• (crycode-de) Fixed Blockly for the latest JavaScript adapter changes
• (crycode-de) Updated dependencies

2.3.0 (2024-05-14)

• (crycode-de) 💥 Node.js 18+ is now required!
• (crycode-de) Added support for custom bot activities
• (crycode-de) Fixed Issue with embed colors not accepting hex color codes
• (crycode-de) Fixed user activities for users with custom activities (see #60)
• (crycode-de) Updated dependencies

2.2.1 (2024-04-13)

• (crycode-de) Fixed blockly target detection if user is provided by a variable (You may need to move a block to update the generated code)
• (crycode-de) Updated dependencies

2.2.0 (2023-11-07)

• (crycode-de) Optimized error handling - Network related errors should now be handled completely without adapter restarts and better logging
• (crycode-de) Fixed small issues in config UI
• (crycode-de) Updated dependencies

2.1.2 (2023-09-04)

• (crycode-de) Fixed response to notification-manager adapter

2.1.1 (2023-08-27)

• (crycode-de) Updated dependencies
• Updated translations

2.1.0 (2023-07-12)

• (crycode-de) Added support for unique user names
• (crycode-de) Detect possible DNS errors during login to prevent restart loops
• (crycode-de) Better handling for login errors, first 4 errors are now logged just as info

2.0.0 (2023-06-11)

• (crycode-de) Updated discord.js to v14
• (crycode-de) 💥 Breaking: Activity types and channel types are now in title case. Example: PLAYING is now Playing, GUILD_TEXT is now GuildText.
• (crycode-de) 💥 Breaking: In raw states all type field values are now numbers representing the internal enum values of the types.
• (crycode-de) Add support for messages from the notification-manager adapter
• (crycode-de) Updated dependencies
• (crycode-de) Added Ukrainian translations
• Updated translations

1.1.6 (2022-07-28)

• (crycode-de) Fixed voice channel member count/list

1.1.5 (2022-07-27)

• (crycode-de) Made token validation less strict

1.1.4 (2022-07-14)

• (crycode-de) Fixed crash if custom command choices name was empty

1.1.3 (2022-07-01)

• (crycode-de) Dependency updates

1.1.2 (2022-06-23)

• (crycode-de) Fixed adapter termination on discord errors to let the js-controller restart the adapter

1.1.1 (2022-06-08)

• (crycode-de) Added support for text messages in voice channels
• (crycode-de) Added support for custom slash commands
• (crycode-de) Added Blockly support with special custom blocks
• (crycode-de) Send error replies on slash commands as ephemeral
• (crycode-de) Added config option to send all slash command replies as ephemeral
• (crycode-de) Register get/set commands only if states are configured for this
• (crycode-de) Choices for commands are now handled as autocomplete which allows more choices, is more dynamic and shows the choices only to authorized users
• (crycode-de) Added command options to raw.interactionJson json content
• (crycode-de) Fixed command name checks
• (crycode-de) Fixed some crashes / stuck conditions when network is not available
• (crycode-de) Fixed several small bugs

1.0.2 (2022-05-16)

• (crycode-de) Fixed some small issues found on adapter review

1.0.1 (2022-05-15)

• (crycode-de) Added possibility to let the bot leave a Discord server
• (crycode-de) Fixed crash on server updates

1.0.0 (2022-05-13)

• (crycode-de) First release

License

MIT License

Copyright (c) 2022-2026 Peter Müller peter@crycode.de

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions:

The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software.

THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.
